Tekbox推出全新的DC LISN TBLDC32-2(PVDC)
发布时间：2024-08-27信息来源：国测
Tekbox推出全新的DC LISN TBLDC32-2(PVDC)
根据CISPR 16-1-2和CISPR 11标准测量9 kHz至30MHz范围内直流线路上的传导发射。该装置设计用于测试半导体功率转换器和类似设备直流电源端口的干扰电压，直流电源电压最高可达1000V和32A。
Frequency range: 9 kHz to 30 MHz
Max. continuous current: 25A
Max. current for 15 minutes: 32A
Max. DC – voltage: 1000 V
Mode A, mode B impedance: 150 ± 30 Ω
Common mode impedance: 150 ± 30 Ω
Differential mode impedance: 150 ± 30 Ω
Phase at EUT-port: 0 ± 40°
EUT-port to AE-port isolation, CM: > 20 dB
EUT-port to AE-port isolation, DM: > 40 dB
Longitudinal conversion loss: > 26 dB
Voltage division factor: 20 ± 3 dB
DC-resistance: 80 mΩ per path typ.
